Car Electric Aerial Wing Mount Replacement Universal Automatic Antenna Fitting Kit

Specification:Model: BF-686AColour: Black Capacity: 80±-3PFVoltage: DC12VCurrent: 0.8AMPCable length: 1200 mmLength of development: 750mm (outside the length of the car)Under the fender: 325mmWeight: 635gMaterial: body stainless steel, steelWiring (three) connection method: red line is connected to the positive pole of the power supply, black line is grounded with the ear, and the green line has two connections: one is the direct current positive pole, so the antenna rises and falls with the power supply on and off, and the other is connected. Control line so that the antenna can be controlled at any time.Stainless steel automatic antennaFeatures: FM radio is good Low noise and good waterproof Easy to install External high quality micro relay, long service life 3C-2V coaxial cable, impedance 75 ohms Installation angle: 0-30 degreesPackage includes:1x Antenna kit10X Antenna cap2X Mounting screw2X Copper cap1X Eight-hole iron piece1X Drain tube

• ▶[Scope of application]: car antenna After upgrading to an IC chip, the signal is more stable and has good AM/FM performance. Good waterproof performance, low noise; easy to install. Suitable for all 12V cars.
• ▶[Connection method]: (three wires) The red wire is connected to the positive pole of the power supply, and the black wire is grounded through the terminal. There are two wiring methods for the green wire: 1. Directly connect the positive pole of the ACC power supply, and the antenna will rise and fall as the ignition switch is turned on and off. 2. In addition, connect the radio control line, so that the antenna can be controlled at any time.
• ▶[Material]: stainless steel + plastic; current: 0.7±0.2A; working voltage: DC12V; plug: ISO DIN plug, built-in miniature relay, 3C-2V coaxial cable.
• ▶[Parameter]: Voltage range: DC10-14V; cable length: 1.2m; extension: 750mm; under the fender: 325mm; cable: 75 ohm cable, line length 1.5m, automatic stainless steel mast signal receiving effect is good, noise is less than 50DB .
• ▶[Note]: The correct connection line must conform to the wiring diagram in order to work normally. Product quality is guaranteed. Every car antenna is strictly reviewed when it leaves the factory. If the connection wire is wrong, the antenna will not work properly.
